AMCX-FDX-2/B

2 Port 10/100/1000Mbit/s AFDX®/ARINC664P7
Test, Simulator and Monitor Module for PMC

  • Specifications
  • Documents
  • Software
  • Related Products
  • Contact
Specifications

AFDX®/ARINC664P7 Test and Simulation module for PMC with 2 full duplex ports programmable for 10/100/1000 MBit/s.
Versions available for both Airbus and Boeing variants of ARINC664P7.

  • Test, verification and simulation of AFDX®/ARINC664P7 End Systems, Switches and Networks
  • Support for Single or Redundant AFDX®/ARINC664P7 operation
  • Support for Boeing ARINC664 extensions for EDE at the hardware interface layer
  • Receive modes: Chronological Monitoring and Recording (100% Wire Speed) plus UDP Port/VL oriented receive
  • Transmission modes: Generic Transmit Operation, Physical Replay and End System Simulation mode
  • TAP mode: to analyse the network traffic between 2 attached network devices (inline)
  • Physical Error Injection/Detection
  • Provisions for network latency measurement and analysis
  • IRIG-B Time Encoder/Decoder
  • Generic Tx/Rx Function Only and Simulator Tx/Rx Function Only versions available
  • Compatible to Standard Ethernet applications
  • Drivers for 32/64-bit Linux and 32/64-bit Windows
  • Optional Network Test and Analysis and ARINC615A Dataloader Software
Documents
  • Data Sheet
  • Release Notes
  • User Manuals
Data Sheet
AMCX-FDX-2
Download AMCX-FDX-2 18-04-09 899.52 KB
Release Notes
User Manuals
Software
  • Windows
Windows
Related Products
ACP-1
ACP-1

PCI Carrier Card with 1 PMC Slot

See details
AVC-2
AVC-2

VME Carrier Card with 2 PMC Slots

See details
ACC-1
ACC-1

CPCI (3U) Carrier Card with 1 PMC Slot

See details
ACPe-1
ACPe-1

PCIe Carrier Card with 1 PMC Slot

See details
PBA.pro-AFDX®/ARINC664P7
PBA.pro-AFDX®/ARINC664P7

AFDX®/ARINC664P7 Resource Component

See details
PBA.pro-ETH
PBA.pro-ETH

Standard Ethernet Resource Component

See details
PBA.pro-FD/-FD-NET/-FD-CLIENT
PBA.pro-FD/-FD-NET/-FD-CLIENT

Framework and Designer Component

See details
PBA.pro-x-DBM
PBA.pro-x-DBM

Database Manager Component

See details
PBA.pro-TSM
PBA.pro-TSM

Test and Script Manager Component

See details
PBA.pro-UA
PBA.pro-UA

User Administration Component

See details
EasyLOAD-615A
EasyLOAD-615A

ARINC615A Data Loading Software

See details
EasyLOAD-DT
EasyLOAD-DT

ARINC615A Data Loading Libraries

See details
PBA.pro-SCR-SW-TEST
PBA.pro-SCR-SW-TEST

ARINC664 Switch - Compliance Tests

See details
PBA.pro-SCR-ES-TEST
PBA.pro-SCR-ES-TEST

ARINC664 End System - Compliance Tests

See details
