PBA.pro-FD

The PBA.pro Framework and the PBA.pro Designer Component together form the
PBA.pro-FD, the core of any PBA.pro System.

  • Specifications
  • Documents
  • Software
  • Accessories
  • Related Products
  • Contact
Specifications
  • This component is mandatory for any PBA.pro based system.

The main task of the PBA.pro framework is to host PBA.pro components for setup and control of locally installed interface hardware as well as components which extend the PBA.pro functionality.

The PBA.pro-FD-NET is an optional extension of the PBA.pro-FD, which allows the use of remotely installed interface hardware over a network connection and supports 1 or more PBA.pro Clients, also connected via network.

A PBA.pro Client is a special version of the PBA.pro-FD for monitoring and visualization of data bus traffic and associated parameters on a remote machine, e.g. via a local network.

The PBA.pro Designer component is an easy to use drag and drop tool to design and build your own, user-defined dialogs for visualization and control of any PBA.pro information or data source. This allows to easily tailor the PBA.pro display and control features to meet individual and unique needs for any user application.

The PBA.pro Software install package from the ‘Software’ Tab of this page includes all PBA.pro components. Components to be installed can be selected by the user during the installation process. An individual PBA.pro license key enables the corresponding PBA.pro components.
