APU429-x

USB 2.0 Module for
ARINC429 Test and Simulation

  • Specifications
  • Documents
  • Software
  • Related Products
  • Contact
Specifications
Aim Module Apu429 Rear 170820

USB 2.0 module for ARINC429 Test and Simulation with 16 (8Tx/8Rx) channels plus 8 bi-directional Discrete I/O’s.

  • Robust and low power USB2.0 module with 16 ARINC429 channels powered via USB – no external power adapter required
  • Hot Plug capability
  • Ruggedised D-Sub connector
  • Cyclic/Acyclic/FIFO Transmitter operation
  • Loop/Pollution mode (Receive-Modify-ReTransmit)
  • Full Error injection/Detection capability
  • Multi Level Triggering for Capturing/Filtering
  • Real Time Recording and Synchronised Replay of all ARINC429 channels concurrently
  • IRIG-B Time Encoder/Decoder for Data Correlation
  • Drivers for 32/64-bit Linux and 32/64-bit Windows
  • Optional Databus Test and Analysis Software
Documents
  • Data Sheet
  • Release Notes
  • User Manuals
  • Tutorials
